SBR UU Series
Description
On beddings with shaft sub-support, the ball bearing group can be connected to the system via cage blocks.
Cage block enables stabile bedding of ball bearing and its easier integration to system.
Offers bedding options that can be safely used in machine and automation systems.
Additional information
| Type | SBR 16 |
|---|---|
| G | 32 |
| W | 45 |
| L1 | 10 |
| M | 45 |
| S1 | M5 |
| J | 32 |
| K | 30 |
| h | 20 |
| H1 | 11 |
| Dynamic Kg | 774 |
| Static Kg | 1180 |
| Weight (gr) | 150 |
